Product Details:
Payment & Shipping Terms:
|
Product Description
Main details
| Standard: | GB/T3091 – 2001, BS1387 – 1985, DIN EN10025, EN10219, JIS G3444:2004, ASTM A53, ASTM A53: GR. A , GR. B, |
| Zinc Coating | 275 – 600g /m2 |
| Steel Grade: | Q195, Q235, Q345, S235, S235JR, S355JR.STK400 /500. |
| Packing: | Packed in bundles with several steel strips, Two tags on each bundle, Wrapped in waterproof paper |
| Test: | Chemical Component Analysis, Mechanical Properties (Ultimate tensile strength, Yield strength, Elongation), Technical Properties (Flattening Test, Bending Test, Blow Test, Impact Test), Exterior Size Inspection, Hydrostatic Test, X-ray Test. Third party inspection:SGS, BV, Lloyds etc. |
| Usage: | Stainless steel pipe can be used for low pressure liquid delivery, such as water, gas, and oil; it can also be used to make fence, greenhouse and other structures. |
Material Quality of mild steel pipe
| ElementsMaterial | Chemical Composition% | Mechanical Property | ||||||
| C% | Mn% | S% | P% | Si% | Yield Point | Tensile Strength | Elongation (%) | |
| (Mpa) | (Mpa) | |||||||
| Q195 | 0.06-0.12 | 0.25-0.50 | <0.050 | <0.045 | <0.30 | >195 | 315-430 | 32-33 |
| Q215 | 0.09-0.15 | 0.25-0.55 | <0.050 | <0.045 | <0.30 | >215 | 335-450 | 26-31 |
| Q235 | 0.12-0.20 | 0.30-0.70 | <0.045 | <0.045 | <0.30 | >235 | 375-500 | 24-26 |
| Q345 | <0.20 | 1.0-1.6 | <0.040 | <0.040 | <0.55 | >345 | 470-630 | 21-22 |
Size
| Outer Diameter | Wall Thickness | Length | |
| Inch | mm | mm | meter |
| 1/2" | 21.3mm | 0.6mm-3.0mm | 0.3m-12m |
| 3/4" | 26.9mm | 0.6mm-3.0mm | 0.3m-12m |
| 1" | 33.4mm | 1.0mm-3.0mm | 0.3m-12m |
| 1-1/4" | 42.3mm | 1.0mm-4.0mm | 0.3m-12m |
| 1-1/2" | 48.3mm | 1.0mm-4.0mm | 0.3m-12m |
| 2" | 60.3mm | 1.5mm-4.0mm | 0.3m-12m |
| 2-1/2" | 76.1mm | 1.5mm-4.0mm | 0.3m-12m |
| 3" | 88.9mm | 1.5mm-9.5mm | 0.3m-12m |
| 4" | 114.3mm | 2.0mm-9.5mm | 0.3m-12m |
| 5" | 141.3mm | 3.0mm-9.5mm | 0.3m-12m |
| 6" | 168.3mm | 3.0mm-12.0mm | 1.0m-12m |
| 8" | 219.1mm | 3.2mm-12.0mm | 1.0m-12m |
| 10" | 273mm | 3.2mm-12.0mm | 1.0m-12m |
| 12" | 323.8mm | 6.0mm-15.0mm | 1.0m-12m |
| 14" | 355.6mm | 8.0mm-15.0mm | 1.0m-12m |
| 16" | 406.4mm | 8.0mm-20.0mm | 1.0m-12m |
Products
FAQ
1. How to buy your ideal products?
A: You can provide us your drawing, and we will produce as your drawing. Or we can design as your requirements if you do not have a clear plan.
2. How to pay?
A: TT and L/C are acceptable and TT will be more appreciated.
30% deposit before producing, 70% balance before loading by TT.
3. What is the delivery time?
A: It depends on order quantity.
Generally, the delivery time will be within 12 to 15 days.
4. How to install after the goods destination?
A: We will provide installation instruction and video for you. Technicians will be sent to help you if it is necessary. However, the visa fee, air tickets, accommodation, wages will be provided by buyers.
