Product Details:
Payment & Shipping Terms:
|
Application:
Machinery
Machine tool
Hydraulic/Pneumatic
Pumps/Compressors
Process Industry
Remarks:
All dimensions are for reference only,subject to change.
Packaging & Delivery
Packaging Detail: For press fittings: we pack press fittings in a poly bag to prevent surface scratch, and then pack them inside brown export cartons. For pipe: we pack the stainless steel pipes inside poly bag, so that it can prevent surface scratch, and keep dirts away from the inside of the pipes. If you have special requirement on packing, please tell us.
Delivery Detail: We have stock for delivery at once.
Features:
•Sizes range from 1/16" to " and 2 mm to 38 mm.
•Diverse materials and configurations are available.
•Precision machined components ensure perfect deformation of the ferrules and tubing.
•Hardened threads with smooth surface finish avoid galling and help to extend the fitting service life.
•Female nut threads are silver-plated to reduce the friction against the body threads.
•Radius junction design with elbows provides smooth flow path.
•Every fitting is stamped with size, material, and heat code.
•Fittings are easy to disconnect and retighten.
Technical Data
•Thread Ends
NPT Threads(NPT)
Comply with ASME B1.20.1, SAE AS71051.
Working Pressures:
•The maximum working pressures of t
tubing data.
•The maximum working pressures of the thread ends at ambient temperature are stated above.
•To get the maximum working pressure at elevated temperature, use the maximum working pressure at ambient temperature to
multiply the factors in the form of Elevated Temperature Factors in page 9.
•The whole fitting is rated by the smallest value among its ends.
Installation Instructions:
•tube fittings up to 1" or 25 mm
1. Loosen the nut 1/4 turn from finger-tight position.
2. Insert tubing into the tube fitting, make sure that the tubing rests firmly on the shoulder of the port.
3. Finger-tighten the nut.
4. Tighten the nut 1 1/4 turns with wrench while holding steady the body of the fitting or the valve (Fig.1).
For small-sized fittings (1/16", 1/8" and 3/16", 2 mm, 3 mm and 4 mm), tighten the nut 3/4 turn with wrench (Fig.2).
