Specification:
1.Standard:ISO2531,EN545,EN598,ANSI/AWWA,C151/A21
2.Effective Length:6m/5.7m
3.Internal Lining :Ordinary Portland Cement ,Sulphate resistant cement ,High-aluminal Cement.
4.External coating:Zinc Primer Plus Bitumen or Expoxy Paiting
5. Shipment: By bulk ship or 20'/40' containr
6. Rubber: NBR, SBR, EPDM according to ISO4633/EN681.1
Technical parament.
| DN(mm) | DE(mm) | THICKNESS OF WALL(mm) | WEIGHT OF SOCKET(kg) | TOTAL WEIGHT(kg) | ||||
| K8 | K9 | K10 | 3.4 | K8 | K9 | K10 | ||
| 80 | 98 | 6 | 6 | 6 | 4.3 | 77 | 77 | 77 |
| 100 | 118 | 6 | 6 | 6 | 5.7 | 93.7 | 95 | 95 |
| 125 | 144 | 6 | 6 | 6 | 7.1 | 119 | 119 | 121 |
| 150 | 170 | 6 | 6.O | 6 | 10.3 | 138 | 144 | 144 |
| 200 | 222 | 6 | 6.3 | 6.4 | 18.9 | 183 | 194 | 194 |
| 300 | 326 | 6.4 | 7.2 | 8 | 23.7 | 290 | 323 | 357 |
| 350 | 378 | 6.8 | 7.7 | 8.5 | 29.5 | 359 | 403 | 441 |
| 400 | 429 | 7,2 | 8.1 | 9 | 38.3 | 433 | 482 | 532 |
| 450 | 480 | 7.6 | 8.6 | 9.5 | 42.8 | 515 | 577 | 632 |
| 500 | 532 | 8 | 9 | 10 | 59.3 | 600 | 669 | 736 |
| 600 | 635 | 8.8 | 9.9 | 11 | 79.1 | 791 | 882 | 971 |
| 700 | 738 | 9.6 | 10.8 | 12 | 102.6 | 1009 | 1123 | 1237 |
| 800 | 842 | 10.4 | 11.7 | 13 | 129 | 1255 | 1394 | 1537 |
| 900 | 945 | 11.2 | 12.6 | 14 | 161.3 | 1521 | 1690 | 1863 |
| 1000 | 1048 | 12 | 13.5 | 15 | 237.7 | 1811 | 2017 | 2221 |
Additional : Ductile iron pipe fittings accoding t ISO2531/EN545/EN598
Gate valve according to DIN standard, BS Standard
Other accessories related to Water field
We also can supply according to the Customers' requirement.
7.Packing & Delivery time .
Packing detail:less DN80- DN300 in steel belt, over DN300 by bulk
Delivery time: Agreed by both sides.
8.Payment Terms:
TT IN ADVANCE/ LC AT SIGHT
