ISO2531/EN545/EN598 Ductile iron pipe K9-Class, K10-Class, Class40

Name: ISO2531/EN545/EN598 Ductile iron pipe K9-Class, K10-Class, Class40
Brand: ISO2531/EN545/EN598 Ductile iron pipe K9-Class, K10-Class, Class40
SKU: Ductile iron pipe K9-Class, K10-Clas
Price: 25 USD
Availability: InStock
Rating: 4.7 (181 reviews)

Large Image : ISO2531/EN545/EN598 Ductile iron pipe K9-Class, K10-Class, Class40 Get Best Price

Product Details:

Place of Origin:	Cangzhou, China (Mainland)
Model Number:	Ductile iron pipe K9-Class, K10-Clas

Payment & Shipping Terms:

Minimum Order Quantity:	600 Meter/Meters
Price:	US $25 - 50 / Meter
Packaging Details:	By pallet, or upon your requirement.
Supply Ability:	100000 Meter/Meters per Month

Contact Now

Detailed Product Description

ISO2531/EN545/EN598 Ductile iron pipe K9-Class, K10-Class, Class40

1.The standed: ISO2531/EN545/EN598, K9-Class/K10-Class/Class40
2. Interface Type: T-type, K-Type, N1-type, S-type

DN	Outside Diameter	Wall thickness
	[mm (in)]	[mm (in)]
		Class 40	K9	K10
40	56 (2.205)	4.8 (0.189)	6.0 (0.236)	6.0 (0.236)
50	66 (2.598)	4.8 (0.189)	6.0 (0.236)	6.0 (0.236)
60	77 (3.031)	4.8 (0.189)	6.0 (0.236)	6.0 (0.236)
65	82 (3.228)	4.8 (0.189)	6.0 (0.236)	6.0 (0.236)
80	98 (3.858)	4.8 (0.189)	6.0 (0.236)	6.0 (0.236)
100	118 (4.646)	4.8 (0.189)	6.0 (0.236)	6.0 (0.236)
125	144 (5.669)	4.8 (0.189)	6.0 (0.236)	6.0 (0.236)
150	170 (6.693)	5.0 (0.197)	6.0 (0.236)	6.5 (0.256)
200	222 (8.740)	5.4 (0.213)	6.3 (0.248)	7.0 (0.276)
250	274 (10.787)	5.8 (0.228)	6.8 (0.268)	7.5 (0.295)
300	326 (12.835)	6.2 (0.244)	7.2 (0.283)	8.0 (0.315)
350	378 (14.882)	7.0 (0.276)	7.7 (0.303)	8.5 (0.335)
400	429 (16.890)	7.8 (0.307)	8.1 (0.319)	9.0 (0.354)
450	480 (18.898)	-	8.6 (0.339)	9.5 (0.374)
500	532 (20.945)	-	9.0 (0.354)	10.0 (0.394)
600	635 (25.000)	-	9.9 (0.390)	11.1 (0.437)
700	738 (29.055)	-	10.9 (0.429)	12.0 (0.472)
800	842 (33.150)	-	11.7 (0.461)	13.0 (0.512)
900	945 (37.205)	-	12.9 (0.508)	14.1 (0.555)
1000	1,048 (41.260)	-	13.5 (0.531)	15.0 (0.591)
1100	1,152 (45.354)	-	14.4 (0.567)	16.0 (0.630)
1200	1,255 (49.409)	-	15.3 (0.602)	17.0 (0.669)
1400	1,462 (57.559)	-	17.1 (0.673)	19.0 (0.748)
1500	1,565 (61.614)	-	18.0 (0.709)	20.0 (0.787)
1600	1,668 (65.669)	-	18.9 (0.744)	51.0 (2.008)
1800	1,875 (73.819)	-	20.7 (0.815)	23.0 (0.906)
2000	2,082 (81.969)	-	22.5 (0.886)	25.0 (0.984)
