Product Description
The Features of HDPE Pipe
1. Health: nontoxic, not scaling. It does not contain heavy metal additive and will not breed bacterium
2. Chemical resistance
3. Size: 16mm to 1400mm
4. Thickness: 2.3-102.9mm
5. Pressure Rating: 0.6Mpa,0.8Mpa,1.0Mpa,1.25Mpa,1.60Mpa
6. Color: black, black with blue stripes, other colors available on request
7. Connection: socket fusion joint,butt fusion joint,electro fusion joint,flanged joint
8. Standard: GB/T13663-2000
9. Certification: ISO9001:2008, ISO4427, ect
HDPE Pipe Advantages
1.Nontoxic: no heavy metal additives, would not be covered with dirt or contaminated by bacterium
2.Corrosion Resistant: resist chemical matters or electron chemical corrosion
3.Lower Installation Costs: light weight and ease of installation can reduce installation costs by as much as 50% over metal piping system
4.Higher Flow Capacity: smooth interior walls result in lower pressure loss and higher volume than metal pipe
5.Longevity: more than 50 years under proper use
6.Recycled and Environment-friendly
HDPE Pipe Applications
1.City water pipe network system.
2.Urban and rural drinking water pipeline .
3.Chemical industry, chemical fiber, food, forestry, printing and dyeing, pharmaceutical. light industry, paper-making, metallurgy Industrial pipeline.
4.Agricultural irrigation pipe.
Specification Of HDPE Pipe
| Outer Diameter | Standard Dimensions | ||||
| (mm) | SDR33 | SDR21 | SDR17 | SDR13.6 | SDR11 |
| Normal Pressure(Mpa) | |||||
| 0.6 | 0.8 | 1 | 1.25 | 1.6 | |
| Thickness(mm) | Thickness(mm) | Thickness(mm) | Thickness(mm) | Thickness(mm) | |
| 20 | 2.3 | ||||
| 25 | 2 | 2.3 | |||
| 32 | 2.3 | 2.4 | 3 | ||
| 40 | 2.3 | 2.3 | 3 | 3.7 | |
| 50 | 2.3 | 2.9 | 3.7 | 4.6 | |
| 63 | 2.3 | 2.5 | 3.6 | 4.7 | 5.8 |
| 75 | 2.9 | 3.6 | 4.5 | 5.6 | 6.8 |
| 90 | 2.8 | 4.3 | 5.4 | 6.7 | 8.2 |
| 110 | 3.4 | 5.3 | 6.6 | 8.1 | 10 |
| 125 | 3.9 | 6 | 7.4 | 9.2 | 11.4 |
| 140 | 4.3 | 6.7 | 8.3 | 10.3 | 12.7 |
| 160 | 4.9 | 7.7 | 9.5 | 11.8 | 14.6 |
| 180 | 5.5 | 8.6 | 10.7 | 13.3 | 16.4 |
| 200 | 6.2 | 9.6 | 11.9 | 14.7 | 18.2 |
| 225 | 6.9 | 10.8 | 13.4 | 16.6 | 20.5 |
| 250 | 7.7 | 11.9 | 14.8 | 18.4 | 22.7 |
| 280 | 8.6 | 13.4 | 16.6 | 20.6 | 25.4 |
| 315 | 9.7 | 15 | 18.7 | 23.2 | 28.6 |
| 355 | 10.9 | 16.9 | 21.1 | 26.1 | 32.2 |
| 400 | 12.3 | 19.1 | 23.7 | 29.4 | 36.3 |
| 450 | 13.8 | 21.5 | 26.7 | 33.1 | 40.9 |
| 500 | 15.3 | 23.9 | 29.7 | 36.8 | 45.4 |
| 560 | 17.2 | 26.7 | 33.2 | 41.2 | 50.8 |
| 630 | 19.3 | 30 | 37.4 | 46.3 | 57.2 |
| 710 | 21.8 | 33.9 | 42.1 | 52.2 | - |
| 800 | 24.5 | 38.1 | 47.4 | 58.8 | - |
| 900 | 27.6 | 42.9 | 53.3 | ||
| 1000 | 30.6 | 47.7 | 59.3 | ||
| 1200 | 36.4 | 57.2 | 70.6 | ||
| 1400 | 42.4 | 66.7 | 82.4 | ||
