The introduction of the carbon steel large pipe reducers:
In the piping system,the direction of the line pipe bend is to be changed.Elbow materials:stainless steel, alloy steel, cast iron can be calcined cast iron, carbon steel, nonferrous metal and plastic, etc.
1,Stainless steel, ASTM/ASME A403 WP 304-304 - l - 304 - h - 304 ln - 304 n ASTM/ASME A403 WP 316-316 l - 316 - h - 316 ln - 316 - n - 316 ti ASTM/ASME A403 WP 321-321 - h ASTM/ASME A403 WP 347-347 - h
2,Carbon steel, ASTM/ASME A234 WPB, WPC
3,Alloy: ASTM/ASME A234 WP 11-12-1 - WP WP WP 22 - WP 91-5 - WP WP911
4,Low temperature steel, ASTM/ASME A402 WPL3 - WPL 6
5,High performance steel: ASTM/ASME A860 WPHY 42-46-52-60-65-65
6,Cast steel, alloy steel, stainless steel, copper, aluminum alloy, plastic, argon luo drain, PVC, PPR, RFPP (reinforced polypropylene), etc.
carbon steel large pipe reducers won't produce corrosion, pitting, corrosion or wear and tear.
1,Method to make division can be divided into pushing, pressing, forging, casting, etc.
2,By manufacturing standards can be divided into the national standard, the electric standard, water standard, American standard, Germany standard, Japanese standard, the standard and so on.
3,To differentiate material of carbon steel, cast steel, alloy steel, stainless steel, copper, aluminum alloy, plastic, argon luo drain, PPC, etc
4,According to the radius of curvature points: can be divided into long radius elbow and short radius elbow
The purpose of the elbow:connect two of the same or different nominal diameter pipe,make the line for turning angle.Due to the elbow with good comprehensive performance,so it is widely used in chemical industry, building, water supply, water drainage, oil, light and heavy industry, freezing, sanitary, plumbing, fire protection, electric power, aerospace, shipbuilding and other infrastructure projects.
The aplication of the carbon steel large pipe reducers :
Connect two of the same or different nominal diameter pipe,make the line for turning angle.Due to the elbow with good comprehensive performance,so it is widely used in chemical industry, building, water supply, water drainage, oil, light and heavy industry, freezing, sanitary, plumbing, fire protection, electric power, aerospace, shipbuilding and other infrastructure projects.
The specification of carbon steel large pipe reducers :
| Name | carbon steel large pipe reducers | |
| Products | Elbow,bend equal /reduce tee,concentric/eccentric reducer , cap,flange | |
| Size | Seamless(SMLS) : 1/2"-24" ,DN15-DN600 | |
| Butt Welded (seam) :24”-72",DN600-DN1800 | ||
| Type | LR 30,45,60,90,180 degree SR 30,45,60,90,180 degree | |
| 1.0D, 1.5D, 2.0D, 2.5D, 3D,4D,5D,6D,7D-40D. | ||
| Thickness | SCH10,SCH20,SCH30,STD SCH40, SCH60, XS, SCH80., SCH100, SCH120, SCH140, SCH160, XXS | |
| Standard | ASME,ANSI B16.9; | |
| DIN2605,2615,2616,2617, | ||
| JIS B2311 ,2312,2313; | ||
| EN 10253-1 ,EN 10253-2 | ||
| Material | ASTM | Carbon steel(ASTM A234WPB,,A234WPC,A420WPL6. |
| Stainless steel(ASTM A403 WP304,304L,316,316L,321. 1Cr18Ni9Ti, 00Cr19Ni10,00Cr17Ni14Mo2, ect.) | ||
| Alloy Steel:A234WP12,A234WP11,A234WP22,A234WP5, | ||
| A420WPL6,A420WPL3 | ||
| DIN | Carbon steel:St37.0,St35.8,St45.8 | |
| Stainless steel:1.4301,1.4306,1.4401,1.4571 | ||
| Alloy steel:1.7335,1.7380,1.0488(1.0566) | ||
| JIS | Carbon steel:PG370,PT410 | |
| Stainless steel:SUS304,SUS304L,SUS316,SUS316L,SUS321 | ||
| Alloy steel:PA22,PA23,PA24,PA25,PL380 | ||
| GB | 10#,20#,20G,23g,20R,Q235,16Mn, 16MnR,1Cr5Mo, | |
| 12CrMo, 12CrMoG, 12Cr1Mo | ||
| Surface treatment | Transparent oil, rust-proof black oil or hot galvanized | |
| Packing | In wooded cases or pallets, or as for clients' requirements | |
| Certification | API and ISO 9001:2000 | |
| Payment Term | T/T ,West Union, | |
| Trade Term | FOB,CIF,CFR(30% down payment in advance, balance should before shipment) | |
The service ofcarbon steel large pipe reducers :
We can guarantee the quality of seamless bw carbon steel large pipe reducers with the competitive price. We will try our best to satisfied the requirement of the customer about the seamless carbon steel large pipe reducers products. We do not want to do the one-shot business of the seamless bw carbon steel large pipe reducers . We also can provide some samples of the seamless carbon steel large pipe reducers products .
Packaging & Shipping
carbon steel large pipe reducers Packaging & Shipping
Packing: wooden pallets or wooden cases, or any sea-worthy packing accoring to customers' requirements
Shipping: by boat or by air, up to customer
Loading Port: Qingdao, China, or Tianjin, China
Leading time: 15-25 days after received down payment
