Main details
| Standard: | GB/T 9711 , SY/T 5037 , SY/T5040,API 5L |
| Steel Grade: | GB/T 9711: L175,L210,L245,L290,L320,L360,L390,L415,L450,L485,L555 SY/T 5037SY/T5040: Q235B,Q345BAPI 5L: A, B, X42, X46, X52, X56, X60, X65 X70 |
| Coating Standard: | ANSI/AWWA C104/A21.4 American National Standard for Cement-Mortar Lining for Ductile-Iron Pipe and Fittings for Water ISO 21809 Petroleum and natural gas industries -- External coatings for buried or submerged pipelines used in pipeline transportation systems DIN 30670 Polyethylene coatings of steel pipes and fittings |
| End: | Square ends (straight cut, saw cut, and torch cut). or beveled for welding, beveled, |
| Surface: | Lightly oiled, Hot dip galvanized, Electro galvanized, Black, Bare, Varnish coating/Anti rust oil, Protective Coatings (Coal Tar Epoxy,Fusion Bond Epoxy, 3-layers PE) |
| Packing: | Plastic plugs in both ends, Hexagonal bundles of max. 2,000kg with several steel strips, Two tags on each bundle, Wrapped in waterproof paper, PVC sleeve, and sackcloth with several steel strips, Plastic caps. |
| Test: | Chemical Component Analysis, Mechanical Properties (Ultimate tensile strength, Yield strength, Elongation), Technical Properties (Flattening Test, Bending Test, Blow Test, Impact Test), Exterior Size Inspection, Hydrostatic Test, X-ray Test. |
Size
| Out Diameter | Wall Thickness | Length |
| mm | mm | m |
| 219 | 6-8 | 1-12 |
| 273 | 6-10 | 1-12 |
| 325 | 6-14 | 1-12 |
| 377 | 6-14 | 1-12 |
| 426 | 6-16 | 1-12 |
| 478 | 6-16 | 1-1 |
| 508 | 6-18 | 1-12 |
| 529 | 6-18 | 1-12 |
| 610 | 6-19 | 1-12 |
| 630 | 6-19 | 1-12 |
| 720 | 6-22 | 1-12 |
| 820 | 7-22 | 1-12 |
| 920 | 8-23 | 1-12 |
| 1016 | 8-23 | 1-12 |
| 1020 | 8-23 | 1-12 |
| 1220 | 8-23 | 1-12 |
| 1420 | 10-23 | 1-12 |
| 1620 | 10-23 | 1-12 |
| 1820 | 10-25.4 | 1-12 |
| 2020 | 10-25.4 | 1-12 |
| 2200 | 10-25.4 | 1-12 |
| 2420 | 10-25.4 | 1-12 |
| 2620 | 10-25.4 | 1-12 |
| 2820 | 10-25.4 | 1-12 |
| 3000 | 10-25.4 | 1-12 |
If you cannot find the sizes that you need, please contact us directly, we can produce the pipe according to your special needs.
Products
FAQ
1. How to buy your ideal products?
A: You can provide us your drawing, and we will produce as your drawing. Or we can design as your requirements if you do not have a clear plan.
2. How to pay?
A: TT and L/C are acceptable and TT will be more appreciated.
30% deposit before producing, 70% balance before loading by TT.
3. What is the delivery time?
A: It depends on order quantity.
Generally, the delivery time will be within 12 to 15 days.
4. How to install after the goods destination?
A: We will provide installation instruction and video for you. Technicians will be sent to help you if it is necessary. However, the visa fee, air tickets, accommodation, wages will be provided by buyers.
