ductile iron pipe pricing
| Type | Ductile iron pipe | ||||||
| Specification | DN80-1200 | ||||||
| Details | |||||||
| Standards: | ISO2531-1998/GB13295-2003 | ||||||
| Weight of T-type Ductile iron pipe(class:k9,standard length:6m) | |||||||
| Nominal diameter | Tube | Weight of Interface | Total Weight | ||||
| DN(mm) | Outer diameter DE | Wall Thickness | Weight per meter(kg/m) | (Approximation)(kg) | (Approximation)(kg) | ||
| (mm) | (mm) | (mm) | |||||
| 80 | 98 | 6 | 12.2 | 3.4 | 77 | ||
| 100 | 118 | 6 | 14.9 | 4.3 | 95 | ||
| 125 | 144 | 6 | 18.3 | 5.7 | 119 | ||
| 150 | 170 | 6 | 21.8 | 7.1 | 144 | ||
| 200 | 222 | 6.3 | 30.1 | 10.3 | 194 | ||
| 250 | 274 | 6.8 | 40.2 | 14.2 | 255 | ||
| 300 | 326 | 7.2 | 50.8 | 18.6 | 323 | ||
| 350 | 378 | 7.7 | 63.2 | 23.7 | 403 | ||
| 400 | 429 | 8.1 | 75.5 | 29.3 | 482 | ||
| 450 | 480 | 8.6 | 89.7 | 38.3 | 575 | ||
| 500 | 532 | 9 | 104.3 | 42.8 | 669 | ||
| 600 | 635 | 9.9 | 137.3 | 59.3 | 882 | ||
| 700 | 738 | 10.8 | 173.9 | 79.1 | 1123 | ||
| 800 | 842 | 11.7 | 215.2 | 102.6 | 1394 | ||
| 900 | 945 | 12.6 | 260.2 | 129.9 | 1691 | ||
| 1000 | 1048 | 13.5 | 309.3 | 161.3 | 2017 | ||
| 1100 | 1152 | 14.4 | 362.8 | 194.7 | 2372 | ||
| 1200 | 1255 | 15.3 | 420.1 | 237.7 | 2758 | ||
| 1400 | 1462 | 17.1 | 547.2 | 385.3 | 3669 | ||
| 1500 | 1565 | 18 | 616.7 | 474.7 | 4175 | ||
| 1600 | 1668 | 18.9 | 690.3 | 526 | 4668 | ||
| Mechanical Properties | |||||
| Nominal diameter mm | Tensile strength N/m2 | Yield strength N/m2 | Elongation% | Hardness HB | water pressure test MPa |
| ≤300 | ≥420 | ≥300 | ≥10 | ≤230 | 5 |
| 300—600 | ≥420 | ≥300 | ≥10 | ≤230 | 4 |
| 700—1000 | ≥420 | ≥300 | ≥10 | ≤230 | 3.2 |
| 1200 | ≥420 | ≥300 | ≥7 | ≤230 | 2.5 |
| Corrosion resistance | |||
| 90-day water corrosion(G/cm2) | Corrosion in sea water(G/cm2) | 72 hours 5% hydrochloric acid solution(G/cm2) | |
| Ductile iron pipe | 0.009 | 0.066 | 0.0821 |
| Ordinary gray iron pipe | 0.0103 | 0.073 | 0.6899 |
| Steel | 0.0396 | 0.13 | ≥10 |
| Seismic performance | |
| Pipe | Rate of earthquake damage% |
| Ductile iron pipe | 0.04 |
| Gray cast iron pipe | 0.17 |
| PVC | 0.14 |
| Steel | 1.24 |
