Product Description
| Ductile Iron Wafer Butterfly Valves | ||
| Material Specification | ||
| Part | Materail | EN Spec. |
| Body | Cast Iron | A126 Class B |
| Ductile Iron | A536 Gr.65-45-12 | |
| Disc | Ductile Iron | A536 Gr.65-45-12 |
| Bronze | B148 C95400 | |
| Stainless Steel 304 | A351 CF-8 | |
| Stainless Steel 316 | A351 CF-8M | |
| Shaft | Stainless Steel 410 | A276 S410 00 |
| Stainless Steel 431 | A276 S431 00 | |
| Seat Ring | EPDM /NBR | |
| O-Ring | EPDM /NBR | |
| Bushing | PTFE | |
| Bronze | B62 C83600 | |
| Valve Standard | ||
| ISO 5752/BS5155/BS EN 593/MSS SP-67/API 609 | ||
| Pressure Temprature and Rating | ||
| Working Pressure | 16bar/27.5bar | |
| Testing pressure | Shell: 24bar/37.5bar | |
| Seal: 17.6bar/27.5bar | ||
| Working Temperature | -20°C to 110°C EPDM Seat | |
| -10°C to 80°C NBR Seat | ||
| Suitable Media | Water, Oll& Cas | |
| Description Products | ||
| Size | DN40-DN1200 | |
| End flange | ANSI B 16.1, EN 1092, AS 2129 | |
| Face to face | ANSI B 16.10; EN 558-1 Series 20 | |
| Top flange | ISO 5211 | |
| Related products | 1. Carbon steel nipples and sockets | 2. Flanges |
| 3. Carbon steel butt-welding fittings | 4. Pipes | |
| 5. High-pressure fittings | 6. Valves | |
| 7. P.T.F.E .thread seal tape | 8. Brass fittings | |
| 9. Ductile iron pipe fittings | 10. Copper fittings | |
| 11. Grooved fittings | 12. Sanitary fittings, etc. | |
| Certificate | BSI, ISO9001:2008,FM,UL | |
| Applications | Fresh water, sewage, sea water, air, vapor, food, medicine, oils, alkalis, salt etc. | |
| Buyer’s drawings or designs are available. | ||
| Package | 1. Cartons without pallets. | |
| 2. Cartons with pallets. | ||
| Or as buyer’s requirements. | ||
| Delivery detail | ||
| According to the quantities and specifications of each order. | ||
| Normal delivery time is from 30 to 45 days after receiving the deposit. | ||
